使用与简洁/Brief Introduction：

该的机器组为10-20ml服食药液液滴分装加工方式线中的重点的机器。是由洗瓶、烘干机箱机机和分装封膜处机机所組成，能定时来完成服食药液瓶的洗瓶、烘干机箱、分装和封膜处等动做，是服食药液加工方式厂家直销更梦想的生活设施的机器，完整满足GMP的要求。It’s a major equipment in production line for oral filling, it main used in filling, capping placing and sealing of 10-20ml bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

特别/Characteristic：

◆装量透彻，遏制滴漏问题。装罐定位精更高。High filling accuracy.◆定频无级变速，产出效率可调式，待选择不同于的产出效率。Frequency control, production speed is adjustable, you can choose a different production rate.◆几乎所有电器产品组件均使用進口有名店牌。All electrical components are imported famous brands.◆自功展示计算功能表。Automatically countting function.◆保持选用当地三菱PLCPLC，抗侵扰，工做动态平衡。Controlled by Mitsubishi PLC◆功效平衡，维修清洁非常方便。Stable performance, easy maintenance.◆电脑整个设备样貌选用SUS304不锈碳钢作、与介质学习环节选用316L不銹钢。电脑整个设备完整按GMP规定规划。Outer material is 304 stainless steel, and the material of filling part is 316L stainless steel. The machine is completely designed according to GMP requirements.

技艺主要参数/technical parameters：

符合外形尺寸/Bottle size	10-20ml
生孩子业务能力/Capacity	60-90瓶/秒钟/60-90bottles/min
干燥摄氏度/Dryer tempreture	100-300°
使用水量/Water wastage	0.5m3/h
空气净化水耗量/Purifying water consumption	0.3m3/h
装量精确度/Filling precision	≤1%
供电/Voltage	380V/50Hz
瓦数/Power	33KW
生育线总长/Dimension	3500×1500×1600mm
