功能与间介/Brief Introduction：

远程服务器是被淘汰服用液钢化玻璃纸瓶的新成品，齐全防止了常有服用液钢化玻璃纸瓶的较差成效。该类灌封机选用的塑胶片瓶，往往不所需洗瓶机、晒干机，更不所需酒精消毒，还可以直接性灌封。设备全自動理瓶、进瓶、装灌，装灌量固定，无漏滴，无瓶不装灌。上盖、密封率led光通量100%。此机技术性较为先进，体型小、程序运行固定、躁音低，操作步骤维修费、洗便等亮点，齐全具备GMP规格。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本款型有减速和高速收费站两个年产量供您选。Note: this model has two kinds of low speed and high-speed production for your choice.

特殊性 Characteristic

◆机器适用人群于种种易折瓶口服药液压力容器检验装灌和封膜。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆全部电子产品部件均选取口碑好牌子。All electrical components adopt famous brand◆该机运作形象便利，无瓶不装罐，检定*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折pp可乐瓶灌封机的重要架构与的原理Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型内服液易折塑料管瓶灌封机常见理瓶器、理盖器、主传输程序、同部带摩擦送小瓶置、空罐检漏系统、灌装线构造、去掉系统、具有热熔封构造、自动机小指夹瓶构造、系列伺服变频电动机摩擦上瓶构造与出瓶构造等组建。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆系统实用的口服方式液易折塑料材质瓶、盖是一个定洁净间区产量的，能有药袋材同意证，这些瓶身与底盖经表达和"去开发"后可同时进来灌封间。经过理盖器、理瓶器的半自动专向委培处理，去除正向底盖及瓶身底口朝下的瓶，使专向委培后的包材喂料有原则地进来输送带组件中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定向就业后口服方式液易折氟塑料饮料瓶在输送机铁轨里排Directional oral liquid after folding plastic bottles in conveying rail out easily

技术应用指标technical parameters：

型号model	NLGFY-40	NLGFY-80
装量依据The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
密封率Hot sealing intensity	》99%
装量测量误差The load error	《1.5%
损坏率damage rate	《1.0%
功效power	2KW	3KW
电源适配器Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
单重 Weight	700Kg	800Kg
